• Detection Range: 12m/360°
• SEC (Smart Environmental Control) - Advanced digital signal processing and 3D optics
• Fully remote configurable through APP
• Multiple enrollment method and easy installation design
• Easy replaceable battery with PCB protected
• Frequency hopping against jamming for reliable transmission

Detection Performance

• Detection MethodPassive Infrared
• Detection Range12m
• Detection Angle360°
• Detection Zones172
• Detectable Speed0.3～2m/s
• SensitivityAuto;Low
• White Light Filter6500lux
• Digital Temperature CompensationSupport
• Creep Zone ProtectionSupport

Feature

• Digital ProcessingSupport
• Sealed OpticsSupport
• Tamper ProtectionFront;Rear
• Environment Temperature IndicatorSupport
• Signal Strength IndicatorSupport

Interface

• Power SwitchPower up enrolling
• LED IndicatorBlue (alarm)

Transmission

• Transmission TechnologyTri-X Wireless
• Transmission MethodTwo-Way RF Wireless
• Transmission Frequency868MHz
• Transmission SecurityAES-128 Encryption
• Transmission Range(Free Space)1.6Km
• Frequency HoppingSupport
• Enrolling MethodPower up;Remote ID;QR Code

Electrical Characteristics

• Standard Battery LifeUp to 5 years (standby time)
• Power SupplyBattery powered
• Battery TypeCR123A × 1
• Typical Voltage3V

General

• Operation Temperature-10°C to 55°C (14°F to 131°F)
• Storage Temperature-20°C to 60°C (-4°F to 140°F)
• Operation Humidity10% to 90%
• Dimension(WxHxD)φ101.2 mm x 32.9 mm
• Weight109.5 g
• Mounting Height2.4 m to 4 m
• Mounting MethodCeiling
• Application ScenarioIndoor
